On-The-Go Power
Sleek and lightweight, the microphone weighs only 10.5 g, ensuring comfortable, hassle-free wear and allowing you to travel light. The pocket-sized charging case offers convenient storage and provides up to 36 hours of power, making it perfect for daily use.
Double Your Range
Compared to the previous V series, the transmission range has doubled to 100 meters, making it your perfect partner for long-distance recording.
Choose What Works For You
Single and dual channel options with USB-C, Lightning, and 3.5 mm TRS adapters for connecting your device.
Choose what you need to save time and maximize efficiency.
Choose what you need to save time and maximize efficiency.
Click for Clear
BOYA Audio's one-click noise cancellation technology effectively filters out background noise. Paired with a windshield, your voice will be crystal clear, whether you're on a bustling street or at a concert.
Plug And Play, Hassle Free
The receiver connects directly to your phone without complicated setup,allowing you to easily connect and instantly enjoy high-quality audio experience.
General
| Receiver | UC | DI | 3.5 mm TRS |
| Transmitter | With 1 or 2 mics to choose | With 1 or 2 mics to choose | With 1 or 2 mics to choose |
| Color | Black / White ( Only 2mics have two colors to choose ) | Black / White ( Only 2mics have two colors to choose ) | Black |
Transmitter
| Dimensions | 51.3 × 18.3 × 10.2 mm | 51.3 × 18.3 × 10.2 mm | 51.3 × 18.3 × 10.2 mm |
| Weight | 10.5g | 10.5g | 10.5g |
| Sample Rate / Bit Depth | 48 kHz / 16-bit | 48 kHz / 16-bit | 48 kHz / 16-bit |
| Signal-to-noise Ratio | ＞80 dB | ＞80 dB | 80dB |
| SPL | 120 dB | 120 dB | 120 dB |
| Output Mode | Mono | Mono | Mono / Stereo |
| Noise Cancellation | One-Click | One-Click | One-Click |
| Frequency Response | 20 Hz - 16 kHz | 20 Hz - 16 kHz | 20 Hz - 16 kHz |
| Latency | 25 ms | 25 ms | 25 ms |
| Human Voice Enhancement | x | x | x |
| Low Cut | x | x | x |
| Transmission Range | 100 m | 100 m | 100 m |
| Onboard Recording | x | x | x |
| Built-in Mic | Silicon Microphone | Silicon Microphone | Silicon Microphone |
| Battery Life | 9 h | 9 h | 9 h |
| Clip | Plastic | Plastic | Plastic |
| Display | x | x | x |
| Human-machine Interaction | Via physical buttons | Via physical buttons | Via physical buttons |
| Power Supply | Built-in Lithium-ion Battery | Built-in Lithium-ion Battery | Built-in Lithium-ion Battery |
Receiver
| Real-time Monitoring | x | x | x |
| Playback Without Unplugging Receiver | √ | √ | x |
| Gain Control | x | x | x |
| Power Supply | Via the mobile device connected | Via the mobile device connected | Built-in Lithium-ion Battery |
| Charging while Recording | √ | √ | x |
| Supports Dual Device Output | x | x | √ |
| Adapter Design | x | x | x |
| 3.5mm | x | x | √ |
| Type-C (USB-C) | √ | x | x |
| Lightning | x | √ | x |
Charging Case
| Dimensions | 62 × 38.5 × 79.8 mm | 62 × 38.5 × 79.8 mm | 70 × 38.5 × 79.8 mm |
| Weight | 86.5 g | 86.5 g | 95 g |
| Battery Capacity | 400 mAh | 400 mAh | 850 mAh |
Q1Product not working with an iPhone，what can we do?
Check if the RX receiver indicator is on and ensure the phone screen is on.iPhones need to be unlocked and the recording app open for power supply
Q2Can the product be used while charging the phone?
Yes，Connect the RX product’s Type-C port to a Type-C cable to charge the phone during live streaming or video recording, alleviating battery anxiety.
Q3Why doesn’t the transmitter show charging when connected to a cable?
The transmitter won’t show a charging indicator when powered on. The red light for charging appears only when the device is off.
Q4Why won’t the product pair?
RX and TX pair automatically without manual setup. They connect to devices within range upon powering on.
Q5Why can’t the product pair in a 1-to-2 setup when powered on simultaneously?
Power on the devices one by one for automatic pairing. If pairing fails, restart the products.
Q6How to adjust if the recording volume is too loud or too quiet?
annot be adjusted directly. Use noise reduction mode and adjust the microphone-to-mouth distance for optimal sound.
Q7How to activate noise cancelation?
In pairing mode, power on TX and short-press the blue NR button to enable noise reduction (green light).Press the NR button again to disable it (blue light)
Packing List
User Manual
BY-V3
BY-V3
General
- Receiver (RX)
- UC / DI / 3.5mm TRS
- Transmitter (TX)
- With 1 or 2 mics to choose
- Color
- Black / White
Transmitter
- Dimensions
- 51.3 × 18.3 × 10.2 mm
- Weight
- 10.5 g
- Sample Rate / Bit Depth
- 48 kHz / 16-bit
- SNR (Signal to Noise Ratio)
- ＞80 dB
- Max SPL
- 120 dB
- Output Mode
- ×
- Noise Cancellation
- One-Click
- Frequency Response
- 20 Hz - 16 kHz
- Latency
- 25 ms
- Human Voice Enhancement
- ×
- Low Cut
- ×
- Transmission Range
- 100 m
- Onboard Recording
- ×
- Built-in Mic
- Silicon Microphone
- Battery Life
- 6 h
- Clip
- Plastic
- Display
- ×
- Human-machine Interaction
- Via physical buttons
- Power Supply
- Built-in Lithium-ion Battery
Receiver
- Monitoring
- ×
- Playback Without Unplugging Receiver
- BY-V35: ×
BY-V3 / V30 / V3 Combo: √
- Gain Control
- ×
- Power Supply
- BY-V3 / V30 / V3 Combo: Via the mobile device connected
BY-V35: Built-in Lithium-ion Battery
- Charging while Recording
- BY-V35:×
- Supports Dual Device Output
- BY-V35:√
- Adapter Design
- ×
- 3.5 mm
- BY-V35: √
- USB-C
- BY-V30 / V3 Combo: √
- Lightning
- BY-V3 / V3 Combo: √
Charging Case
- Dimensions
- BY-V3 / V30 / V3 Combo: 62 × 38.5 × 79.8 mm
BY-V35: 70 × 38.5 × 79.8 mm
- Weight
- BY-V3 / V30 / V3 Combo: 86.5 g
BY-V35: 95 g
- Battery Capacity
- BY-V3 / V30 / V3 Combo: 400 mAh
BY-V35: 850 mAh
